How to speed up the 3ds Max program and save time?

If you happen to do more complex scenes, then sooner or later your program starts to feel slower. Sometimes it even starts to be so annoying that it can significantly impede our work, which translates into a longer time of its execution.

However, do not worry! There are many ways to speed up the program. If you follow the advice given below, it will certainly improve the operation of the program and will translate into the speed of project implementation.

  • Use Vray Proxy

If you use objects that consist of a large number of polygons, such as trees or cars, be sure to replace them with a V-ray Proxy! With this option, the size of your files will not grow and the Viewports will work much faster. Thanks to this option it is possible, for example, to render practically unlimited number of trees. It is worth remembering that in the options Render Setup -> Settings -> System -> Dynamic memory limit, increase the number of megabytes.

Use Vray Proxy
  • Set the V-ray Proxy objects to Display – Bounding Box

If you want to speed up the work with V-ray Proxy objects, it is worth changing the options for displaying them in the “Bounding Box” scene. A very useful script that facilitates control over them is Proxy Tools.

Set the V-ray Proxy objects to Display - Bounding Box
  • Use object copying – Instance

Not only does it accelerate the program’s operation, it can significantly reduce the size of files. Even if you copy one object a hundred times, for example, it takes 1 MB, it will still be 1MB! For comparison, if you copy as copy, it will already be 100MB!

 Use object copying - Instance
  • Limit the number of lines (splines) to a minimum

If you use DWG underlays, try to clean them from all unnecessary lines before importing them. We recommend deleting all unnecessary blocks, and especially pay attention to objects such as trees, cars, people. If, despite minimizing the number of lines in the scene, the program is still not going smoothly, we recommend to hide them with Shift + S when they are not needed.

Limit the number of lines (splines) to a minimum
  • Use layers

Order in the scene is an important thing. Especially if someone else will work on your file. In addition, thanks to the layers, you can easily hide objects that you do not need at work on the stage at the moment. For example, things like furniture, trees, vegetation.

3ds max layer system
  • Set the display of objects as “Box”

If you have to leave some complicated objects in the scene, it is best if you set “Display as Box” in the Object Properties

Set the display of objects as "Box"
  • Complicate complex objects to Editable Mesh

If you have finished editing the object, which consists of many polygons, then it is worth thinking about converting it to Editable Mesh. Not only does this accelerate the operation of Viewports, but additionally, objects of this type take up less disk space than eg. Editable Poly!

Complicate complex objects to Editable Mesh
  • Limit the number of objects in the scene to a minimum

A very large number of objects can often make it impossible to work freely. If, for example, you have 500 pieces of steel balustrade in the scene, then it is worth considering whether to combine them into one object. It can sometimes increase the file size on the disk, but it will significantly speed up the program.

Limit the number of objects in the scene to a minimum
  • Use XRef

If in the scene you use models that consist of many polygons, and you do not plan to edit them often, it is worth considering whether to use the XRef option. How it’s working? For example, if you do not want your scene to be loaded with furniture, all you need to do is select it and use the “Convert Selected” option in the XRef Scenes options. Thanks to this, the furniture will be saved to a separate file and if necessary we can make it invisible in our stage and finally be visible on the renderer!

Use XRef
  • Turn off displaying textures in Viewports

It’s always nice to have a preview of the textures on our objects, but in a situation where we want to speed up the program, we can turn them off. A very helpful script that will save you a lot of time is Turn Viewport Maps On / Off.

Turn off displaying textures in Viewports
